Technical specifications

Model H6M

Motherboards ITX / MICRO ATX

VGA Clearance 405mm

CPU Cooler Clearance 160mm

3.5+2.5 Driver Bays 2+1

Power Supply 170mm

Chassis Dimension 410*210*430mm

Product Dimension 413*210*450mm

40HQ Container 1050 PCS

I/O Ports USB3.0*2 + HD Audio

Air Cooling Top: 120mm x 3 or 140mm x 2 Rear: 120mm x 1 MB cover :120mm x 2 PSU cover :120mm x 3

Liquid Cooling Top :240mm/280mm/360mm Rear: 120mm

Body Materiarl SPCC 0.5mm

Front Panel 3mm glass side panel

Left Panel 3mm glass side panel

Right Panel 0.5mm Metal
