L140-H4
-
TDP200W
-
Heat Pipe4PCS
-
Heat Pipe Dimensions6mm
-
Fan Size120*120*25mm
-
Fan Connector5V 3Pin + PWM 4Pin
-
SupportAMD5 / INTEL 1700
Technical specifications
Model
L140-H4
TDP
200W
Dimensions Size
120*48*148mm
Heat Pipe
4PCS
Heat Pipe Material
Cu1020
Heat Pipe Dimensions
φ6mm
Fin Material
Aluminum
Support
AMD 5 / INTEL 1700
Fan Size
120*120*25mm
Fan Bearing
Hydro Bearing
Fan Rated Voltage
DC 12V
Fan Speed
800-1800rpm ±10%
Fan Airflow
62.93CFM
Fan Static Pressure
1.75mm H2O
Fan Connector
5V 3Pin + PMW 4 Pin
Contact Surface
Direct touch
